Full workshop manual for Breva 1100 models covering maintenance, overhaul and detailed repair

Includes tolerances for many parts. n.b. These are comb bound reprints

 2 in stock

 854310 MG854310

Dimensions:
A4 11 chapters black & white

Full workshop manual for the 1100 Sport Carb model covering maintenance, overhaul and repair. This only partially covers the 1100 Sport injection models.

This is a comb bound reprint

 1 in stock

Dimensions:
A4 - 132 pages black & white

Oil pressure switch. May be supplied with a vertical spade connector, this supercedes the original Guzzi part which is no longer available. This oil pressure sensor will fit without removal of the alternator

See ENA12640 for replacement crush washer and ELA10005 for female spade connector

 More than 5 in stock

 31768780 GU31768780 31 76 87 80
 3176 8780 3176.8780 31.76.87.80

Dimensions:
M12 x 1 thread, 32mm height from top of thread

Brakelight switch for handlebar mounted master cylinder

Stop light switch also known as Guzzi ref. 30530526. Please compare with your existing switch to check compatibility. Can be used as a substitute for ELA27815 or ELA30860. Sometimes supplied with three terminals, in this instance disregard middle terminal. Please note that terminals are smaller than standard switch and will need to be soldered on.

 3 in stock

 30749860 GU30749860 30 74 98 60
 3074 9860 3074.9860 30.74.98.60

Dimensions:
20mm x 6mm x 9mm excluding spade connectors

Side stand mounting bolt with shoulder

 1 in stock

 99105129 GU99105129 99 10 51 29
 9910 5129 9910.5129 99.10.51.29

Dimensions:
M10 x 22mm

Swingarm bearing oil seal

Dust seal for swingarm bearing

 More than 5 in stock

 90403040 GU90403040 90 40 30 40
 9040 3040 9040.3040 90.40.30.40

Dimensions:
40mm OD

Manually operated fuel tap or fuel valve for models with carbs. Includes cable and remote side panel mounted knob

These new taps have a linkage that may be shorter than the original tap. In this case, you will need to swap over the linkage from your old tap and re-use it. Before using the tap you will need to release it by rotating the brass section behind the tap by quarter of a turn (anti-clockwise)

 3 in stock

 29105450 GU29105450 29 10 54 50
 2910 5450 2910.5450 29.10.54.50

Dimensions:
21mm threaded section, 153mm linkage from fuel tap to brass head of cable

Thottle cable, runs from twistgrip to carb

We advise you to measure your existing cable before ordering in case you have a non standard set up.

 3 in stock

 19117580 GU19117580 19 11 75 80
 1911 7580 1911.7580 19.11.75.80

Dimensions:
1020mm outer length, 96mm free length, 5.7mm barrel nipple, 2.7mm barrel nipple

Round 12v two pin flasher relay

See FRA17720 for rubber mount, item may look different to this please take into consideration before ordering.

 More than 5 in stock

 17750520 GU17750520 17 75 05 20
 1775 0520 1775.0520 17.75.05.20

Dimensions:
32mm diameter

Clutch cable with adjuster for gearbox end

Suitable for all T3 and T4 models fitted with high bars

 2 in stock

29093000-z 29093000 GU29093000 29 09 30 00
 2909 3000 2909.3000 29.09.30.00

Dimensions:
1444mm outer length, 80mm free length, 9.9mm barrel nipple, 9.9mm barrel nipple
