Replacement clutch plate for single plate RAM clutches

Torque setting for fitting this is 25Nm with a thread locking compound

 This part is available by special order, request a quote

Set of matt finish aluminium rocker covers. Ideal for finishing off your restoration project, these can be fited to square barrel models if fitted with adapter kit ACA30310

This rocker cover set also known as Guzzi ref. 14923602 and 14023502. Includes tapped holes for breather pipe banjo bolts

 This part is available by special order, request a quote

 14923602 GU14923602 14 92 36 02
 1492 3602 1492.3602 14.92.36.02

Set of matt finish aluminium loop frame rocker covers. This rocker cover set is ideal for finishing off your restoration project, these can be fited to square barrel models if fitted with adapter kit ACA30310

 This part is available by special order, request a quote

 12023501 GU12023501 12 02 35 01
 1202 3501 1202.3501 12.02.35.01

Complete electronic ignition kit containing alternator mounted ignition pickup, fittings and amplifier unit. Works with 12 volt 3 Ohm coils ELA14500 (big twins) and can be used to replace Digiplex on models with Ducati charging systems where the bike is converted to carburettors. This kit is just an ignition system, it will not control fuelling. The pickups for this kit are mounted on the alternator stator. Supplied with instructions in German with wiring diagrams.

2 year warranty on Sachse ignition kits

Once fitted no further adjustment should be necessary. Preloaded with nine ignition curves, two of which are designed for twin plugged bikes. See this link for fitting instructions. Some bikes may need at least one additional spacer to allow enough clearance for alternator cover to fit once pickup is fitted. Note that if you are replacing a Digiplex system you will also need to replace your 'square' coils with higher impedance 12 volt coils e.g. ELA14500

 This part is available by special order, request a quote

Complete sump kit which moves the oil filter out from within the sump to a recess under the sump. This simplifies and speeds up oil changes because the sump no longer needs to be removed. Oil cooling is also improved because oil will cool through the body of the filter. The complete sump kit is a simple fit that will speed up oil changes and reduce the risk of stripping crankcase bolts through repeated sump removal. It is very similar to the arrangement on modern CARC models. Replaces sump extension ENA14002. Finished in silver this is a great upgrade for your Guzzi. Uses oil filter SIA14530

Depending on model you may need a longer dipstick e.g. ENA28495. You can calibrate the sump by adding 3l of oil and marking the position on the dipstick. Note that you need to transfer your oil pressure relief valve and the intake screen from your existing sump into this new one. Note also that the stamped steel covers on some oil pressure relief valves flare wider than others so you may need to make a little clearance in order to get the threads started. Also available at additional cost in black by special order - ENA14006

 This part is available by special order, request a quote

Black Plastic Number Plate Bracket

 This part is available by special order, request a quote

 31438765 GU31438765 31 43 87 65
 3143 8765 3143.8765 31.43.87.65

Pair of chromed Hepco and Becker pannier frames for Hepco and Becker panniers. These high quality German frames bolt to the grab rail and footrest hangers. Once fitted you have a choice of Hepco and Becker panniers that can be mounted on your bike

Photo shows black version

 This part is available by special order, request a quote

Pair of black Hepco and Becker pannier frames for Hepco and Becker panniers. These high quality German frames bolt to the grab rail and footrest hangers. Once fitted you have a choice of Hepco and Becker panniers that can be mounted on your bike

 This part is available by special order, request a quote

Agostini rearset kit comprising of black levers, footpeg hangers, fixed knurled alloy footpegs, necessary linkages and fittings. Retains standard silencer bracket position

This is a high quality Italian kit with black tubular footrest hangers which retains the looks of the original parts on a Le Mans 1 or Le Mans 2. Includes pillion footrests. To fit these to the NT version of the 1000 SP you will need to either fit upswept silencers and Le Mans type H pipe or fabricate suitable silencer brackets

 This part is available by special order, request a quote

Agostini rearset kit comprising of black levers, fixed knurled alloy footpegs, necessary linkages and fittings. Retains standard silencer bracket position

This is a high quality Italian kit with black tubular footrest hangers which retains the looks of the original parts on a Le Mans 3. Kit does not include pillion footrests but the original pillion footrests from the bike can be used with this kit

 This part is available by special order, request a quote
